WS2812B Led Lights DC5V WS2812 RGB Led Strip Light Individually Addressable Smart Pixels Magic Light Black White PCB IP30 65 67

Features:

Input Voltage:DC 5v.

Power: 30leds/m—-9watt/meter; 60leds/m—-18watt/meter; 74leds/m—-22watt/meter; 96leds/m—-28.8watt/meter; 100leds/m—-30watt/meter; 144leds/m—-43.2watt/meter.

LED: Each LED is separately controlled, every LED is cuttable.

IC Type: ws2812 IC(built inside the 5050 smd rgb led), (1 IC drives 1 led chip).

Pixels: 30/60/74/96/100/144/meter.

FPCB Width: 30leds/m—-10mm; 60leds/m—-10mm; 74leds/m—-12mm; 96leds/m—-12mm; 100leds/m—-10mm; 144leds/m—-12mm.

FPC Color: Black/White.

Protection rate: IP30 Non-Waterproof; IP65 Waterproof in Silicon Coating; IP67 Waterproof in Silicone Tube.

Package: In anti-static bag, IP30 IP65 with adhensive tape on the back. (IP67 without adhensive).

The different between the WS2812B and WS2812B-ECO.

1, LED Chip Material:

9pcs Pure Gold Line, Copper Bracket (WS2812B).

9pcs Admixture Gold Line, Brass Bracket (WS2812B-ECO).

2, LED IV Value Brightness:

Red: 400-700mcd, Green: 1000-1500mcd, Blue: 200-400mcd (WS2812B).

Red: 500-700mcd, Green: 1300-1800mcd, Blue: 300-500mcd (WS2812B-ECO).

3, Warranty Period of Led Strip:

36 Months (WS2812B), 18 Months (WS2812B-ECO).

4, Suggestions on Product Application:

Such as Park, Square, Hotel, Airport, Office Building, Shopping Mall, Coffee Bar, KTV, Supermarket, etc (WS2812B).

Usually applied to Parlour, Bedroom, TV light, Karaoke Television light, Computer light, DIY and Home decoration, etc (WS2812B-ECO).
