Tuya Curtain Roller Shutter US 120 Standard Switch Smart Life Remote Control Motor Running Time Setting Google Assistant Alexa

Note before Order!

– Input Voltage: 100~250VAC, 50/60Hz；Output Voltage(Motor Voltage): 100~250VAC, 50/60Hz(Our switch can’t work with DC motor!)
– Please check your motor is with 4 wires (Blue Wire, Brown wire, Black Wire, Green/Yellow Wire) before you buy our curtain switch module. And please be noted that neutral wire is a must for the installation, or you can’t use our device.

Features

• Voice Control:
Compatible with Amazon Alexa, Google Assistant.

• App Remote Control:
– Support Smart Life APP /Tuya APP.
– Mobile app remote control to open or close curtain.

• Timer and Schedule:
You can set a timer to open or close the curtains at a specified time.

• Running Time Setting:
The running time can be set from 1-120 seconds, suitable for the use of large blinds.

• Touch Panel Control:
Manual control of the device through the glass touch panel for safe operation with wet hands.

• Group Control:
Group control of devices and sharing of devices with family members.

• Device Sharing:
You can create group in the APP to manage all the blinds in your house and share the devices to all your family members.

• Personalize Scene Settings:
With Smart Life scene settings, you can flexibly set your curtain status according to sunrise, sunset or weather conditions.

Specification

Input voltage: 100-250VAC, 50 / 60Hz
Wiring: Neutral Wire, L1, L2, Earth Wire
Max Load: 600 W
Wirelss Type: Wi-Fi 2.4 GHz 802.11 b / g / n (Not support 5Ghz)
Standby Consumption: below 0.5W
Dimensions: 120mm * 72mm * 39mm
APP Name: Smart Life or Tuya APP

What’s in the box?

1 * US Standard Smart Curtain Switch
1 * User Guide
1 * Terminal
1 * Blue Cable to install on curtain switch
4 * Screws
