Parking Car Rear View Camera CCD HD Brake Light 4.3 Inch Monitor for FIAT Ducato CITROEN Jumper PEUGEOT Boxer 2006-2015



High Performance Digital Super Clarity Image processor.
The camera is mounted in a ball socket which only moves in one plane so is easy to setup and can be adjusted by the end user who would like to fine tune the image — to suit their individual requirements.
The camera comes with a long extension cable, allowing trouble free installation to suit even the longest wheelbase models.
The camera also incorporates reversing guidelines to help you reverse.
Fitments:
For FIAT Ducato 2006-2015
For CITROEN Jumper 2006-2015
For PEUGEOT Boxer 2006-2015
Voltage: 12V DC
Power: 12W
Contrast ratio:350:1
Sensor 1/4 PC7070 CMOS
Mirror head: F = 1.7mm
Viewing angle: 170 degrees
Mini Lumination: 0 Lux (IR*6)
TV System: PAL
TV line:480TVL
Horizontal Sync Frequency : 15625kHz
Aspect ratio:4:3 ,Resolution:480*272
Resolution: 648(H) x 488(V)
Signal to noise ratio: more than 48dB (AOC on)
Post rate: 30fps
Minimum illumination: 0.5Lux
Lens: Waterproof :IP68
Output line: power supply, signal line, ground line
Video output: composite video cable (75 Euro)
Operating temperature: -20 Celsius ~ +70 Celsius, RH95%
Storage temperature: -40 Celsius ~ +85 Celsius, Rh 95%
AGC: Auto
BLC: Auto
Colour: black
Material: plastic

Package Contents:
1 * camera
1 * 4.3 inch display Screen
1 * power cord
1 *10m video cable
1 * English manual
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
