Haute42 M Gen2 Aluminium Alloy Hitbox Leverless Controller Stickless Arcade Stick For PC/Ps4 /Ps5 Hitbox Fighting Controller

Haute42 Aluminium Alloy Hitbox Leverless Controller Stickless Arcade Stick For PC/ Ps4 / ps5/Steam /Switch Hitbox Fighting Controller

NOTE: If you want to connect to PS4 or PS5, you will need a converter or an dongle. Our store also has converters available for you to purchase together

Product Description

Working voltage: 5V

Link method: USB Type-C

Product size: 300mm * 200mm * 13.5mm Key cap Size:23.8 mm

Supported Platforms : pc /ps3/ps4/switch/ Android/Steam

Product Specifications:1Mini Keyboard,1Data Cable Type-C,1Keycap Puller, 4 anti slip pads

HautePad M-Ultra Gen 2

New Metal CNC spraying process instead of CNC anodizing（More durable, more stain-resistant）The anodized process is ultra-thin, not bulky at all, compact and easy to carry, uses a crystal low -profile switches, it is has a cool appearance with RGB and Ambient LEDS mode, M-ULTRA 1 Upgrade Edition，Optimized wrist area curve, Shadow hunting switches,The controller is bigger and thinner, worth having

01 Compatibility

B — Xinput mode (Windows/Steam)

A — SWITCH mode

X — PS3 / Dinput mode (Raspberry Pi / Android)

Y — PS4 mode (Compatible with PS4 games on PS5 console）

RT — KEYBOARD mode

Input Mode

To change the input mode, hold one of the buttons(as shown above) as the controller is plugged in.

Tips：

This product defaults to Xinput mode，Input mode is saved across power cycles.

PS4 /PS5 Mode

About PS4 /PS5 8 minute disconnection，there are two ways， one is insert a dongle or a officially authorized PS4 wired controller to the EXT.port，We don’t have a recommend one，there are too many choices，maybe you can add our discord with other nice players in haute42 group，oficial Website：www.haute42.com

Web Configurator

This product contains a built-in web-based configuration application which can be started up by holding START when plugging your controller into a PC. Then access //192.168.7.1 in a web browser to begin configuration.

TURBO

Hold TURBO，then press the button which you need to be set for turbo function，then this button will be continuous sending while you press it,to cancel this turbo key，just repeat the privious step.

The turbo key that set will be cleard when power off.

These keys can be set as a Turbo key: A / B / X / Y / LB / RB / LT / RT

04 RGB LED Setting

●BACK + START + X Next Animation

●BACK + START + A Previous Animation

●BACK + START + Y Brightness Up

●BACK + START + B Brightness Down

●BACK + START + RB LED Parameter Up

●BACK + START + RT LED Parameter Down

●BACK + START + LB Pressed Parameter Up

●BACK + START + LT Pressed Parameter Down
