70kg Digital Servos Large Torque Magnetic Induct 8.4v Brushless Motor IP68 Steel Helical Gear For 1/8 1/10 Remote RC Car Robot

70KG High Torque High Voltage Metal Gear Digital Servo IP68 Brushless Motor Robot Servo for 1/10 1/8 TRX6 scx10 RC Crawler

Features

– Metal Gear

– Semi-metal case

– Brushless

– IP68

Description

weight: about 90g

Size: 4.05*2.1*4.17cm

Operating Voltage: 6.0-8.4V DC

Standby Current: ≤20mA

Stall Current 6.0V:≤5A

Stall Current 7.4V:≤7A

Stall Current 8.4V:≤9A

Rated Torque: 6.0V: ≥10kg.cm

Rated Torque: 7.4V: ≥14kg.cm

Rated Torque: 8.4V: ≥16kg.cm

No Load Speed 6.0V: ≤0.12sec/60°

No Load Speed 7.4V: ≤0.10sec/60°

No Load Speed 8.4V: ≤0.09sec/60°

Max.Torque 6.0V: ≥ 55 kgf.cm

Max.Torque 7.4V: ≥ 63 kgf.cm

Max.Torque 8.4V: ≥ 70 kgf.cm

Rotating Direction: ccw(500-2500us)

operating Travel Angle: 180±10°(500~2500us)

Max.Operating Travel Angle: 358°±10°(500~250Ous)

Neutral Position: 1500us

Reduction ratio: 1:299

Dead Band Width: ≤2us

operating Temperature Range: -20℃~+80C

waterproof rating: IP68

Packing list

1 X Servo with accessories

color box packing
