433Mhz RF Remote Control Wireless Switch DC 5V 12V 24V 1CH rf Relay Receiver and 2CH Transmitter For Door Electromagnetic lock

433Mhz RF Remote Control Wireless Switch DC 5V 12V 24V 1CH rf Relay Receiver and 2CH Transmitter For Door Electromagnetic lock

Working Modes: 4 modes
Momentary mode,Toggle mode,Latched mode and Time delay mode

Momentary mode: Press and hold A button, will work;Release A button,will stop.
Toggle mode: Press A button,will work;press A button again,will stop;
Press B button,will work;press B button again,will stop.
Latched mode: Press A button,will work;Press B button again,will stop.
Time delay mode:  Press and hold on button “A” , turn on;
Release the button, turn off after 5 seconds(or 10/15 seconds )

How to program
Momentary mode: Press learning button once,press A button once,succeed.
Toggle mode: Press learning button twice,press A button once,Press B button,succeed.
Latched mode: Press learning button 3times,press A button once;press the B button once.succeed.
Time delay mode: Press learning button 4/5/6 times,press A button once,succeed.

Reset:
Press the learning button 8 times. The existing data will be deleted succeed.
