12V 24V FOXSUR FPT200 FPT100 Car Battery Charger for Moto for Truck Battery Repair for Lead-Acid AGM LiFePo4 EFB GEL WET

Please NOTE：

What is the difference between FPT-100 and FPT-200？

FPT-100 is Yellow.
FPT-100 Output Current: 12V 10A & 24V 5A
FPT-100 Input Power With Load Max.: 150W

FPT-200 is Red.
FPT-200 Output Current: 12V 20A & 24V 10A
FPT-200 Input Power With Load Max.: 300W

FPT-200 12V 20A & 24V 10A

FPT-100 12V 10A & 24V 5A

Portable Automatic Car Start-Stop Battery Charger

* MULTIPLE PROTECTION
* WINTER SUMMER
* MULTIPLE MODE
* PULSE REPAIR
* BATTERY DETECTION

7-STAGE CHARGING PROCESS

1-stage: Battery desulphation

2-stage: Soft start charging

3-stage: Bulk charging

4-stage: Absorption charging

5-stage: Battery test

6-stage: Recondition charging

7-stage: Float & maintenance charging

MULTIPLE MODES:

The Charger has seven (7) modes: 12V AGM+(LiFePo4), 24V AGM+(LiFePo4), 12V Car, 24V Car, 12V Motorcycle, 24V Motorcycle, REPAIR.

It is important to understand the differences and purpose of each charge mode. Do not operate the charger until you confirm the appropriate charge mode for your battery. Below is a brief description:

12V/24V SMART CHARGER

EASY TO USE:12/24V volt lead-acid for Motorcycle and car

CHEMISTRIES: Flooded,gel,maintenance free,LiFePo4 and AGM batteries.

TYPES. Starter: deep-cycle,marine, powersport and more.

REPAIR MODE: Advanced repair mode for idle or old batteries.

AUTO TEMPERATURE DETECTION

The charger automatically adjusts the charging voltage according to the am
temperature.

STEPS FOR USING 12V BATTERY

STEP1: Plug in the household 220V power supply.
STEP2: Select the corresponding mode.
STEP3: Red clamp clamps the positive pole of the battery. Black clip clips the negative electrode of the battery, Start charging now.

STEPS FOR USING 24V BATTERY

STEP1: Connect two 12V batteries in series.
STEP2: Plug in the household 220V power supply.
STEP3: Select the corresponding mode.
STEP4: Red clamp clamps the positive pole of the battery. Black clip clips the negative electrode of the battery, Start charging now.

FPT200 FOXSUR Car Battery Charger

Specifications:

Types of batteries: Most types of lead acid batteries including Calcium, Gel AGM, Wet, LiFePO4, lead Acid, etc..
Polarity protechtion: Yes
Switchmode technology: Yes
Output short protection: Yes
Over voltage protection: Yes
Non battery link protection: Yes
Over temperature protection: Yes
Cooling: Fan
Input voltage: 100-240V AC, 50-60Hz
Rated output: 12V 20A & 24V 10A
Minimum start voltage: 5.0V
Compliant standards: CE/FCC/RoHS

FPT100 FOXSUR Car Battery Charger

Specifications:

Types of batteries: Most types of lead acid batteries including Calcium, Gel AGM, Wet, LiFePO4,lead Acid, etc..
Polarity protechtion: Yes
Switchmode technology: Yes
Output short protection: Yes
Over voltage protection: Yes
Non battery link protection: Yes
Over temperature protection: Yes
Cooling: Fan
Input voltage: 100-240V AC, 50-60Hz
Rated output: 12V 10A & 24V 5A
Minimum start voltage: 5.0V
Compliant standards: CE/FCC/RoHS

FOXSUR FPT200 12V 20A & 24V 10A Pictures

FOXSUR FPT100 12V 10A & 24V 5A Pictures
